This innovative system makes your living spaces comfortable in all seasons thanks to its natural air conditioning and ventilation feature.
The axial movement mechanism optimizes air flow and provides temperature control by directing sunlight according to need.
The Sky Line Series, which has manual and motorized options, brings together both aesthetics and functionality with its modern design and high durability.
Another feature of this system, where water insulation is excellent, is that it allows ventilation even in rainy weather when the panels are at certain angles.
Manufactured with Winperax quality, this bioclimatic system offers superior performance, stylish design and long-lasting use for both individual and commercial areas.
SKY LINE SERIES AXIAL BIOCLIMATIC TECHNICAL SPECIFICATIONS
1) All profile parts used in the system are ALUMINUM.
2) Aluminum profiles used in the system are 6063 – T6 F25 (7580 Briner Hardness).

3) Each system module consists of vertical and horizontal carrier profiles. Vertical main carriers are 160mm*160mm*2.5 mm, horizontal main carriers are 60mm*246mm*2.5 mm.

Panel profile is 233mm*456mm*2 mm.

4) Since the system has grooves on 4 sides, it prevents water intake without any slope. Water is discharged from the front or rear foot (pillar) profiles.

5) With the hidden groove in the system panels, water is discharged to the side grooves, and from the side grooves to the foot (pillar) profiles.

6) During the axial movement of the system panels, the hidden curtain profile in the side grooves also moves. This feature is designed to prevent light and wind from outside.
7) The panels work axially. This feature is important in terms of being able to perform ventilation and shading at the same time.
8) The system has a manual gearbox reducer option that provides axial movement and a tubular motorized axial movement option. Wind/rain/sun sensor can be applied in motorized options.
9) LED lighting can be applied to all edges in the system.
10) Metal accessories are first galvanized and then painted with electrostatic oven paint.
11) Panels can move axially at the desired angle (maximum 105 degrees).
12) All aluminum profiles are painted with electrostatic powder paint technology.
13) The screws used in the system are chrome stainless.
14) All connection flange elements in the system are hiddenly detailed.
15) The wicks to be used in the system are EPDM gaskets.
16) The system has a 2-year automation and 2-year mechanical parts warranty
